HFO-1234yf SERIES 109 MODEL 89 POWER COUPLER (LOW-SIDE)

Features

  • PLC controllable
  • Automatic operation
  • Leak-free positive lock
  • Quick connect/disconnect
  • Long-lasting
  • Economical

Provides for instant positive connecting onto the HFO-1234yf low side process fitting for evacuation or refrigerant charging with automatic disconnect at cycle completion. Holding pressure from vacuum to 600 psig.

Application

  • Vacuum
  • Refrigerant
  • Oil
  • Low side fitting

Specifications

  • Characteristic: For HFO-1234yf Low Side Fitting
  • Coupler Style: Power Charging Coupler
  • Stem Extension: 10 to 10.5 mm (SAE J639 Standard)
  • Air Pilots: Clamp Air
  • Factory Air Supply: 60 psig/ 4.2 kg/cm2
  • Air Port Fitting: 1/4″ Dia. One Touch Connectors
  • Weight: 1.15 lbs/ 0.5 kg
  • Vacuum Indicating Range: ATM – 10 microns Torr
  • Vacuum Flow: 2.8 SCFM
  • Fluid & Vacuum Port Fitting: 3/8″ JIC Flare
  • Refrigerant: HFO-1234yf at 600 psig max. (42 kg/cm2)
  • Process Fitting Nose Seal: Molded
  • Process Fitting Clamp System: PCU BalLoc
  • Oil Compatibility: Polyolester of PAG
  • Flow Rate: 0.55 Cv
ADAPTER TYPE

Power Coupler
